The wood pellet boiler is a single cylinder longitudinal type boiler with water and fire tube shell, and the combustion equipment is a chain grate. The wood pellet boilers prices is reasonable, the water wall on the left and right sides of the furnace is radiant heating surface, and the two wings of the furnace is convective heating surface. The convection heating surface of threaded smoke pipe is arranged in the boiler drum. The furnace wall is made of a new process of heat-resistant concrete integral pouring and ramming. The outer side of the main boiler is a three-dimensional shell of protective plate.
This series of boilers belong to a kind of biomass boilers, the body in the overall structure of the upper cylinder, water wall tube and collection box symmetrical arrangement of the form. The cylinder is welded together with the cylinder body and the front and rear tube plates. The boiler furnace layout is reasonable and the combustion efficiency is high. This series of boilers adopt new scientific research achievements, such as: arch tube plate, screw smoke pipe, etc., to solve the boiler shell type tube plate crack, water wall burst tube, low thermal efficiency, insufficient output, poor adaptability of biomass and other problems.
This series of boiler products have a wide range of applications, mainly can be used in farming and animal husbandry, greenhouse planting, seed factory, livestock slaughterhouse; Toy factory of chemical industry, refinery, feed factory, coating factory, plastics factory, glass factory, glass manufacturing, paper mills, textile mills, milk factory, brewery, food factory, shoe factory, ceramics factory, furniture factory, setting, cigarette factories, mat factory, chopsticks, printing, adhesive tape factory, hardware factory, floor factory, cabinet factory, wood factory. Bathing, hotels, schools, etc. Wood pellet boilers prices is reasonable, its role is mainly for heating, heat preservation, drying, heating, melting, supply of production, sterilization, vulcanization, hot water supply, etc..
The technical characteristics of the boiler is outstanding, using the arch type tube plate and screw pipe composition of the drum, the drum from the quasi steel body into quasi elastomer structure, cancel the tubular-plate area pull support, reduce the stress. The problem of crack in tube plate was solved by changing the double return pipe into single return pipe. Due to the arrangement of rising pipe row at the bottom of the drum, the dead water area at the bottom of the drum is eliminated, so that the sludge is not easy to deposit, the high temperature area of the drum can get good cooling and prevent the bulge at the bottom of the drum.
The combustion process of biomass fired boiler is mainly fuel fed into the chain grate by the feeder and then into the furnace combustion, the flue gas generated along the bottom of the drum through the outlet smoke window on the wall into the two wings convection tube bundle, through the front smoke box into the threaded smoke pipe, through the economizer, dust collector, by the induced draft fan pumping through the chimney into the atmosphere. The wood pellet boilers prices is competitive, the boiler runs stably, the adjustment is convenient, the output is sufficient. Zozen Boilers adopt heat transfer screw pipe to enhance heat transfer effect, achieve the characteristics of high temperature and pressure increase, and improve the thermal efficiency of the boiler. Compact structure, compared with the same type of boilers, the size of the shape is small, saving the boiler room capital investment.
